2022
Kawasaki
Mule PRO-FXT Ranch Edition Platinum
Stock #UNB5012335
‹
›
Reset Zoom
X
‹
›
-
+
‹
›
Check Availability
Hi, my name is
First Name
Last Name
and I'm interested in this
2022 Kawasaki Mule PRO-FXT Ranch Edition Platinum
. I'm in the
Zip Code
area and you can reach me at
Email
or by phone at
Phone
Is this unit still available?
What payment terms are available?
When can I test ride this unit?
Phone
MarketingName
HarleyName
SubModel
SubscriberId
SubscriptionId
VehicleId
Year
ModelName
MakeDivision
ReturnURL
EPriceForm
InstantPrice
CampaignName
CampaignType
Submit
Details
Status:
New
Vehicle:
2022 Kawasaki Mule PRO-FXT Ranch Edition Platinum
VIN:
JKBATSE17NB501235
Model Number:
KAF820MMFNL
Stock Number:
UNB5012335
Title:
Clear
Location:
Columbia Powersports Supercenter
Warranty:
Manufacturer's w/ Extended Available
Specifications
BRAKES
Front Brake Diameter (in):
8.3
Front Brake Diameter (mm):
212
Front Brake Type:
Dual Hydraulic Disc
Rear Brake Diameter (in):
8.3
Rear Brake Diameter (mm):
212
Rear Brake Type:
Dual Hydraulic Disc
DRIVE LINE
Differential Lock Location:
Rear
Driveline Type:
Selectable 4X2 / 4X4
Limited Slip Differential Location:
Front
Number Of Driveline Modes:
2
Rear Unlocking Differential:
Yes
ENGINE
Bore (in):
2.83
Bore (mm):
72
Carburetion Type:
Fuel Injected
Compression Ratio:
9.5
Cooling:
Liquid
Cylinders:
3
Displacement (cc):
812
Displacement (ci):
49.5
Engine Brand Name:
Kawasaki
Engine Stroke:
4-Stroke
Engine Type:
In-Line
Fuel Injector Size (mm):
34
Fuel Injector:
Yes
Fuel Requirements:
Regular
Fuel Type:
Gas
Horsepower (bhp):
48
Horsepower (kW):
35
Horsepower RPM:
5500
Speed Governor:
Yes
Starter:
Electric
Stroke (in):
2.62
Stroke (mm):
66.5
Torque (Ft Lbs):
48
Torque (Nm):
65
Torque RPM:
3500
Valve Configuration:
DOHC
Valves Per Cylinder:
4
Valves:
12
EXTERIOR
Bash Plate (Front):
Yes
Body Material:
Plastic
Brush Guard:
Yes
Cab Canopy Material:
Hard
Cab Door Material:
Hard
Frame:
Steel
Radiator Guard:
Yes
INSTRUMENTATION
Fuel Level Warning Type:
Gauge
Temperature Warning Type:
Light
LIGHTS
Type:
LED
SEATS
Folding:
Yes
Number Of Rows:
2
Number Of Seats:
6
Seat Material:
Vinyl
Seat Type:
Bench
STEERING
Steering Control:
Steering Wheel
Steering Type:
Power
STORAGE
Bed Capacity (kgs.):
453
Bed Capacity (lbs.):
999
Bed Height (in):
11
Bed Height (mm):
279.4
Bed Length (in):
42.7
Bed Length (mm):
1084.6
Bed Volume (ft3):
14.6
Bed Volume (m3):
0.4
Bed Width (in):
53.7
Bed Width (mm):
1364
Cargo Bed Material:
Steel
Cargo Bed Tilt:
Yes
Number Of Cupholders:
2
SUSPENSION
Front Suspension Type:
Independent Double Wishbone
Front Travel (in):
8.7
Front Travel (mm):
221
Number Rear Shock Absorbers:
2
Rear Suspension Type:
Independent Double Wishbone
Rear Travel (in):
8.7
Rear Travel (mm):
221
TECHNICAL SPECIFICATIONS
Fuel Capacity (gal):
7.9
Fuel Capacity (l):
29.9
Ground Clearance (in):
10
Ground Clearance (mm):
254
Height (in):
79.5
Height (mm):
2019.3
Length (ft):
11.68
Length (ft/ft):
11
Length (ft/in):
8.2
Length (in):
140.2
Length (mm):
3561
Payload Capacity (kgs):
733.2
Payload Capacity (lbs):
1616.3
Towing Capacity (kgs):
907.2
Towing Capacity (lbs):
2000
Turning Radius (ft):
16
Wet Weight (kg):
923
Wet Weight (lbs):
2035.2
Wheelbase (in):
92.3
Wheelbase (mm):
2344.4
Width (in):
64
Width (mm):
1625.6
TOWING & HAULING
Rear Hitch Type:
Receiver
Size (cm):
5.1
Size (in):
2
Weight (kgs):
2041.2
Weight (lbs):
4500
Winch Brand Name:
Warn®
TRANSMISSION
Hi / Low Range:
Yes
Primary Drive (Engine / Transmission):
Belt
Primary Drive (Front Wheel):
Shaft
Primary Drive (Rear Wheel):
Shaft
Reverse:
Yes
Transmission Type:
Continuously Variable (CVT)
WHEELS & TIRES
Front Tire (Full Spec):
Duro
Front Tire Diameter (in):
26
Front Tire Width:
9
Front Wheel Diameter:
12
Rear Tire (Full Spec):
Duro
Rear Tire Diameter (in):
26
Rear Tire Width:
11
Rear Wheel Diameter:
12
Tire Brand:
Duro
Tube / Tubeless:
Tubeless
Wheels Composition:
Aluminum
